- Features :Fixed / Field Adjustable
- Accuracy :± 2% / CL 2%
- Repeatability :± 2% /CL 2
- Ranges :1…..160 bar
- Mounting :Bottom
- Wetted Parts :Bottom Body , Diaphragm / Piston
- MOC :SS304/SS316
- Process Connection :1/4″BSP(M)
- Options :Option: 1/8″ / 3/8″ / 1/2″- BSP / NPT / MM
- Max. Process Temp. :100°C
- Ambient Temp. :-20 .. 150°C
- Switch Type & Rating :1SPST, 5A / 220 VAC – Contact Type
- Switch Type :NO / NC
