RTD WELD PAD /SURFACE MOUNTING MODEL- TGI31-09

• Element :PT-100 / 500 / 1000 , Class A / B
• Range :-200 …. 400 / 600°C
• Wire Combination :Simplex / Duplex , 2 Wire/3 Wire/4Wire
• Accuracy :IEC-751 / DIN 43760
• Sheath Material :SS316 /SS316L / SS310
• Sheath Diameter :3 / 5 / 6 / 8 mm
• Terminal Head Type :Threaded Cover / Hinged / 2 screwed / Weather -IP65/66/68 / Flame Proof / Explosion Proof
• Terminal Head Material :Die cast Alumi / SS304 /SS316
• Cable Entry :3/4″ ET/NPT, 1/2″ NPT, M20
• Head Extension :Adjustable Connection
• Immersion Length :50 mm upto 1000 mm
• Process Connection :1/2″ / 3/4″ – BSP / NPT, M20
• Mounting :Local / No Bracket / with Bracket / 2″ pipe mounting, Bracket / Surface Mounting
• Weld Pad :Rectangle / Integral Collar
• Others :With Transmitter, Terminal Block PCD -33 /46 mm, Single / Double Compression Gland
