| Model Name/Number | LC 1030 |
| Response Time | On to Off 10 – 15 m sec, Off to On 50 – 100 m sec |
| Operating Temperature | Up to 55 Degrees centigrade |
| Vibration Resistance | Amplitude 0.75 mm (p), Frequency 10 – 55 Hz, Rate 1 Octave / min |
| Supply Protection | Reverse Polarity Protected |
| Protected Heights | 90 – 1710 mm |
| Pitch Offered | 11 – 20 – 30 – 40 – 50 – 90 mm |
| Cross Section | 36 x 42 mm |
| Standard Cable Length | 5 meters for emitter, 3 meters for receiver |
| Power Supply | 12 – 24 Volts DC |
Waterproof Safety Light Curtains is available for selected models as shown is photograph. Such housing is required for Emitter and Receiver separately. With such watertight housings, Safety Light Curtains can be used in the area where water is being used extensively for cleaning in nearby area. Without watertight housing, water droplets enters housing of safety light curtain and damages / stops functioning of the unit. It is made from transparent acrylic tube so that IR rays can pass through them.
